68T Hydraulic Mooring Winch with double drums in waterfall

Price: 1.0~150000.0 USD
Payment Terms: T/T
Place of Origin: Jiangsu, China (Mainland)
inquire
Add to My Favorites
HiSupplier Escrow
Share |

Product Detail

Model No.: EXP-YJT-W-68-00
Production Capacity: 5000pcs per year
Delivery Date: 6months
winch: hydraulic winch
Means of Transport: Ocean
Packing: under the customers' requir...
Brand Name: Expansion or OEM

1)Compact costruction, safe & easy operation.
2) Hydraulic Anchor Winch with double drums in waterfall

Specifications Details
Hydraulic Mooring Winch with double drums in waterfall
It consists of a hydraulic motor,spur gears with cover, three main shafts , two drums, ratchet wheel and detent, etc.
Feature
Double drums in waterfall. Two drums can work simultaneously and independently.
Each Drum's load
68T (1st layer)
Each drum's Brake Holding load
79T   (1st layer,)
Nominal speed
68T X 5m/min(High speed,9.8T X20m/min
Drum capacity
Dia.38mm x L1220m (11 layers)   Steel wire rope
Hydraulic motor
BD5 1500/400(SAI)
Manual operated proportional valve
AMCA APV-22
Working pressure
24.76MPa
Winch control
Local control & Remote control including amplifier and joystick
Brake
Hydraulic operated band brake (normally shut)
Clutch
Hydraulic claw clutch
Power
Two units 68T double drums winch share one hydraulic power unit placed in a room with doors. Two winches / 4 drums can work simultaneously and independently.
